Full auto Ice tube blowing molding machine

1. Introduction of SQ-6 ice tube blow molding machine:

This machine is mainly suitable for plastic package with being blown up from side, such as the plastic bottles for eye-drop, fruit juice, milk, medicine, cosmetic etc. The machine adopts screw extruding blow molding technology in its extruder. And it is adopted auto-control temperature and FM activator. The machine is combined with electro motion, pneumatic power and mechanism. The main character of this machine is its simplicity & stabilization of operation. It has been famous for its excellent performance, low maintenance ratio, less consumption of electricity & low noise. May match according to the correlation product this aircraft truncates the mouth equipment automatically.

The products produced by this machine are as blow photo:

Ice Tube

2, Specification:
Max. Bottle Containment:                  1000ml
Productive capacity:                          2500-3500PCS/hr
Allowed Mould width:                        125mm
Allowed Mould Thickness:                118mm
Blowing Air pressure:                        0.4-0.7Mpa
Rated Power:                                    12kw
Extruder Screw Diameter:                55mm
Plasticizing Capacity:                         35KG/Hour
Size of Main Frame(L.W.H):              650*3100*1650mm
Weight:                                            1500kg
